Wrapping Guide
1. PVC Gloss Protective Film
2. Colloidal Scratch Resistant Coating
3. High-Grade Polymeric Vinyl
4. Low-Tack Pressure-sensitive Acrylic Adhesive
5. 160 Grams Double Side Silicone-coated Release Liner
Friendly Reminder：
| Recommended application tools | Squeegee, buffer, knife, masking tape, heat gun, magnets, gloves, IRR thermometer, IRR heater, more wrapping pls click HERE |
| Application method | Standard methods for calendered films. No overstretching and overheating and Post heating is necessary. |
| Post-heating temperature | 110°C flat surfaces, 130°C curves, and overlaps |
| Aftercare | PH neutral, Avoid wax or solvents |
Brand
Carwraponline
SKU
1305
Size (mm)
Width: 1520±0.01% Lenth: 1800+1% (Standard roll size)
Top protected film (um)
35±2% (PET/PVC)
Surface materials (um)
110±2% (High-grade PVC-Polymeric)
Glue (um)
28±2% (High performance low initial viscosity acrylic adhesive)
Release liner (um)
170±2% (paper)/120±2% (PET)
Adhesive
Acrylic-based, reposition able, slideable
Release force (N/25mm)
0.13 (25℃ and 50%)
Initial tack (g/25mm)
903 (26℃ and 64%, GB31125-2014)
Peel Strength (N/25mm)
4.5 (25℃and 42%, GB/T2792-1998)
Holding power (h)
75.09 (25℃ and 50%, GB/T4851-1998)
Breaking strength(%)
>200%
Shelf Life
2 years(stored in +10°C to +35°C, relative humidity 50%, in original package, away from direct sunlight, clean and dry place)
Application temperature
From +15℃ to +40℃
Aging Test 1
No adhesive residue with heat(7 days under 65°C)
Aging Test 2
No adhesive residue without heat(10 days under 65°C)
Shrinkage
less than 4%
Expected durability
5-7 years
Skill level needed
Low
Weight
13-13.5Kg
